Research of sea surface gust inversion by dual band radar altimeter data

doi: 10.12284/hyxb2024039

Lin Jing^1
,,
Zhang Youguang^{2
,
,}

1.
National Marine Environmental Forecasting Center, Beijing 100081, China
2.
National Satellite Ocean Application Service, Beijing 100081, China

Received Date: 2024-01-23
Rev Recd Date: 2024-03-25

Available Online: 2024-05-20

Publish Date: 2024-06-30

Abstract

Abstract

Sea surface gusts are important marine dynamic environmental information required for the development of marine resources, marine disaster prevention and reduction, and marine scientific research. However, so far, there has been a serious lack of observational data on sea surface gusts, which has hindered the development of gust forecasting, application research, and other aspects. This article uses the backscatter coefficients in the C and Ku bands of the dual frequency HY-2B satellite altimeter to correct the existing sea surface wind speed ($ {U}_{10} $) and gust wind speed ($ {U}_{{\mathrm{g}}} $) inversion algorithm. The inversion results were verified for authenticity with the buoy data from the National Buoy Data Center (NDBC) of the United States from 2018 to 2022. The correlation coefficient (R) was 0.91, and the root mean square error (RMSE) was 1.82 m/s; based on the inversion results of this method and the NDBC station data from 2018 to 2022, the RMSE of similar foreign satellites Jason-3 is superior to the conventional 2 m/s accuracy requirement; the inversion results were verified with individual cases of offshore and oceanic stations at different latitudes, and the RMSE was better than 2 m/s. Therefore, based on the existing HY-2B satellite altimeter sea surface wind speed observation data, this article uses different band information to achieve observation of sea surface gusts, which has high observation accuracy. Meanwhile, this method is also applicable to foreign satellite altimeters with the same observation system.
- radar altimeter,
- inversion method,
- sea surface gusts,
- HY-2B satellite,
- Backscattering Coefficient

FullText(HTML)

References(28)

References

[1]	姜祝辉, 黄思训, 刘刚, 等. 星载雷达高度计反演海面风速进展[J]. 海洋通报, 2011, 30(5): 588−594. Jiang Zhuhui, Huang Sixun, Liu Gang, et al. Research on the development of surface wind speed retrieval from satellite radar altimeter[J]. Marine Science Bulletin, 2011, 30(5): 588−594.
[2]	大气科学名词审定委员会. 大气科学名词[M]. 3版. 北京: 科学出版社, 2009. Approval Committee of Atmospheric Science Terms. Chinese Terms in Atmospheric Science[M]. 3rd ed. Beijing: Science Press, 2009.
[3]	李永平, 郑运霞, 方平治. 2009年“莫拉克”台风登陆过程阵风特征分析[J]. 气象学报, 2012, 70(6): 1188−1199. Li Yongping, ZhengYunxia, Fang Pingzhi. Analysis of the characteristics of gusts during the landing of Typhoon Morakot (2009)[J]. Acta Meteorologica Sinica, 2012, 70(6): 1188−1199.
[4]	Jung C, Schindler D, Buchholz A, et al. Global gust climate evaluation and its influence on wind turbines[J]. Energies, 2017, 10(10): 1474. doi: 10.3390/en10101474
[5]	Larose G L, Mann J. Gust loading on streamlined bridge decks[J]. Journal of Fluids and Structures, 1998, 12(5): 511−536. doi: 10.1006/jfls.1998.0161
[6]	岑国基, 张金根. 大跨度桥梁施工抗风设计问题[J]. 桥梁建设, 1988(3): 57−63, 56. Cen Guoji, Zhang Jingen. Wind-resistant design of long-span bridge construction[J]. Bridge Construction, 1988(3): 57−63, 56.
[7]	Kwon S D, Chang S P. Suppression of flutter and gust response of bridges using actively controlled edge surfaces[J]. Journal of Wind Engineering and Industrial Aerodynamics, 2000, 88(2/3): 263−281.
[8]	魏晓琳, 王德立, 贺佳佳, 等. 深圳沿海地区阵风系数的特征[J]. 广东气象, 2016, 38(5): 33−36, 41. Wei Xiaolin, Wang Deli, He Jiajia, et al. Characteristics analysis on gust factors over coastal areas in Shenzhen[J]. Guangdong Meteorology, 2016, 38(5): 33−36, 41.
[9]	尹尽勇, 刘涛, 张增海, 等. 冬季黄渤海大风天气与渔船风损统计分析[J]. 气象, 2009, 35(6): 90−95. Yin Jinyong, Liu Tao, Zhang Zenghai, et al. Statistical analysis of the weather system types causing strong winds and fishery boat windage loss accidents in Bohai Sea and Yellow Sea in winter[J]. Meteorological Monthly, 2009, 35(6): 90−95.
[10]	丁杏农. 浅谈横风使船舶产生横漂的机理[J]. 云南交通科技, 1997, 13(1): 46−48. Ding Xingnong. A brief discussion on the mechanism of transverse drift of ships caused by crosswind[J]. Yunnan Communication Science and Technology, 1997, 13(1): 46−48.
[11]	荣艳敏, 阎丽凤, 盛春岩, 等. 山东精细化海区风的MOS预报方法研究[J]. 海洋预报, 2015, 32(3): 59−67. Rong Yanmin, Yan Lifeng, Sheng Chunyan, et al. A study on MOS forecasting method of gale wind in Shandong coast[J]. Marine Forecasts, 2015, 32(3): 59−67.
[12]	Brasseur O. Development and application of a physical approach to estimating wind gusts[J]. Monthly Weather Review, 2001, 129(1): 5−25. doi: 10.1175/1520-0493(2001)129<0005:DAAOAP>2.0.CO;2
[13]	董双林. 中国的阵风极值及其统计研究[J]. 气象学报, 2001, 59(3): 327−333. Dong Shuanglin. Gust extremes in China and its statistical study[J]. Acta Meteorologica Sinica, 2001, 59(3): 327−333.
[14]	Fan Lei, Zheng Chongwei, Zhou Hongjin, et al. Gust characteristic analysis of wind energy resource in the western Pacific Ocean[J]. Journal of Coastal Research, 2020, 99(S1): 404−410.
[15]	胡海川, 刘珺, 林建. 基于预报方程的我国近海阵风预报[J]. 气象, 2022, 48(3): 334−344. Hu Haichuan, Liu Jun, Lin Jian. Application of prediction equation to gust forecasting for Chinese offshore areas[J]. Meteorological Monthly, 2022, 48(3): 334−344.
[16]	张有广, 蒋城飞, 贾永君, 等. HY-2B卫星载荷联合观测海面阵风的一种反演方法[J]. 海洋学报, 2022, 44(11): 133−143. Zhang Youguang, Jiang Chengfei, Jia Yongjun, et al. An inversion method for joint observation of wind gusts by HY-2B satellite remote sensors[J]. Haiyang Xuebao, 2022, 44(11): 133−143.
[17]	Hsu S A, Meindl E A, Gilhousen D B. Determining the power-law wind-profile exponent under near-neutral stability conditions at sea[J]. Journal of Applied Meteorology, 1994, 33(6): 757−765. doi: 10.1175/1520-0450(1994)033<0757:DTPLWP>2.0.CO;2
[18]	Hwang P A, Teague W J, Jacobs G A, et al. A statistical comparison of wind speed, wave height, and wave period derived from satellite altimeters and ocean buoys in the Gulf of Mexico region[J]. Journal of Geophysical Research: Oceans, 1998, 103(C5): 10451−10468. doi: 10.1029/98JC00197
[19]	Gourrion J, Vandemark D, Bailey S, et al. Satellite altimeter models for surface wind speed developed using ocean satellite crossovers[R]. 2000.
[20]	Sharoni S M H, Md Reba M N, Hossain M S. Tropical cyclone wind speed estimation from satellite altimeter-derived ocean parameters[J]. Journal of Geophysical Research: Oceans, 2021, 126(4): e2020JC016988. doi: 10.1029/2020JC016988
[21]	刘花, 王静, 齐义泉, 等. 南海北部近岸海域Jason-1卫星高度计与浮标观测结果的对比分析[J]. 热带海洋学报, 2013, 32(5): 15−22. Liu Hua, Wang Jing, Qi Yiquan, et al. Comparison of Jason-1 satellite altimeter and buoy measurements in the coastal water of the northern South China Sea[J]. Journal of Tropical Oceanography, 2013, 32(5): 15−22.
[22]	Hwang C, Kao E C, Parsons B. Global derivation of marine gravity anomalies from Seasat, Geosat, ERS-1 and TOPEX/POSEIDON altimeter data[J]. Geophysical Journal International, 1998, 134(2): 449−459. doi: 10.1111/j.1365-246X.1998.tb07139.x
[23]	Gower J F R. Intercalibration of wave and wind data from TOPEX/POSEIDON and moored buoys off the west coast of Canada[J]. Journal of Geophysical Research: Oceans, 1996, 101(C2): 3817−3829. doi: 10.1029/95JC03281
[24]	Cotton P D, Carter D J T. Cross calibration of TOPEX, ERS-I, and Geosat wave heights[J]. Journal of Geophysical Research: Oceans, 1994, 99(C12): 25025−25033. doi: 10.1029/94JC02131
[25]	陈戈. 卫星高度计反演海面风速——模式函数与应用实例[J]. 遥感学报, 1999, 3(4): 305−311, 325. Chen Ge. On retrieving sea surface wind speed from satellite altimeters: model functions and an application case[J]. Journal of Remote Sensing, 1999, 3(4): 305−311, 325.
[26]	Farjami H, Golubkin P, Chapron B. Impact of the sea state on altimeter measurements in coastal regions[J]. Remote Sensing Letters, 2016, 7(10): 935−944. doi: 10.1080/2150704X.2016.1201224
[27]	Zappa C J, Laxague N J M, Brumer S E, et al. The impact of wind gusts on the ocean thermal skin layer[J]. Geophysical Research Letters, 2019, 46(20): 11301−11309. doi: 10.1029/2019GL083687
[28]	Lyu M, Potter H, Collins C O, et al. The impacts of gustiness on the evolution of surface gravity waves[J]. Geophysical Research Letters, 2023, 50(12): e2023GL104085. doi: 10.1029/2023GL104085
